Project delivery

Find the orders and tasks affected by a new drawing.

See Vela at work

See what a change affects.

Red Mesa Compute CampusShared project

RMC-E-101 Rev 04

Main Substation Single-Line DiagramIssued by Owen Walsh2d ago

RMC-E-101Rev 04 · where the change goes

Autodesk DocsRMC-E-101 · Rev 04SWGR-A main bus3000 A → 4000 AVelaPurchase order · SAP AribaPO-52210Order for SWGR-A · Grace KimReferences Rev 03 · behind Rev 04PreparedSupplier thread · GmailRE: SWGR-A shop drawingsLast reply 4d agoDrawn to Rev 03 · needs Rev 04PreparedSchedule activity · Primavera P6RMC-CON-2140SWGR-A set on pad · 12 Jan 2027Lead time to reconfirm · dates heldPreparedPNReview ownerPriya Nair3 actions to review

Illustrative record trace. Nothing is issued before review.

Scroll to inspect the drawing.

Hold the SWGR-A change notice for review

Reviewer Priya Nair

PausedRejectApprove exact action

One revision. Follow every dependency.

A higher bus rating reaches beyond the drawing. See which order, supplier conversation and installation date need another look.

Red Mesa Compute Campus

The drawing moved. These records need to follow.

Drawing change

RMC-E-101

Rev 033000 A
Rev 044000 A

SWGR-A main bus

Autodesk Docs
  1. Purchase orderSAP Ariba

    PO-52210

    Order for SWGR-A · Grace Kim

    References Rev 03 · behind Rev 04
  2. Supplier threadGmail

    RE: SWGR-A shop drawings

    Last reply 4d ago

    Drawn to Rev 03 · needs Rev 04
  3. Schedule activityPrimavera P6

    RMC-CON-2140

    SWGR-A set on pad · 12 Jan 2027

    Lead time to reconfirm · dates held
Example project · SWGR-ASchedule dates held until the supplier confirms lead time.
Equipment & procurementUtility & interconnection
